Smart Window Pdlc Film Not Self-Adhesive Glass Films for Privacy

Name: Smart Window Pdlc Film Not Self-Adhesive Glass Films for Privacy
Brand: QJY
SKU: QJY-20240302-01
Price: 125.00 USD
Availability: InStock
Rating: 5 (121 reviews)

Product Details

Place of Origin: Shandong, China

Brand Name: QJY

Model Number: QJY-20240302-01

Payment & Shipping Terms

Minimum Order Quantity: 10 square meters

Price: $125.00/square meters 10-49 square meters

Delivery Time: small quantities 7-15 working days after order

Get Best Price

Product Details

Product Description

Product Details

Highlight:

Warranty:	3 Years	After-sale Service:	Online Technical Support, Onsite Installation, Onsite Training, Onsite Inspection, Free Spare Parts, Return And Replacement
Project Solution Capability:	Graphic Design, 3D Model Design, Total Solution For Projects, Cross Categories Consolidation	Application:	Villa, Indoor Decorative
Design Style:	Modern	Function:	Decorative
Feature:	Not Self-Adhesive	Type:	Glass Films
Surface Treatment:	Opaque	Color:	Milky White,black, Blue And Green
Thickness:	5+5,6+6,8+8etc	MOQ:	10 Square Meters
Packing:	Plywood Cases	Pattern:	Customzied
Transmittance:	80%	Edge:	Matt Edge
Control Method:	Switch Control	Logo:	Acceptable

Warranty:	3 Years
After-sale Service:	Online Technical Support, Onsite Installation, Onsite Training, Onsite Inspection, Free Spare Parts, Return And Replacement
Project Solution Capability:	Graphic Design, 3D Model Design, Total Solution For Projects, Cross Categories Consolidation
Application:	Villa, Indoor Decorative
Design Style:	Modern
Function:	Decorative
Feature:	Not Self-Adhesive
Type:	Glass Films
Surface Treatment:	Opaque
Color:	Milky White,black, Blue And Green
Thickness:	5+5,6+6,8+8etc
MOQ:	10 Square Meters
Packing:	Plywood Cases
Pattern:	Customzied
Transmittance:	80%
Edge:	Matt Edge
Control Method:	Switch Control
Logo:	Acceptable

Product Description

Smart switchable glass is a kind of special architectural glass, also known as atomized glass, energized glass, etc. It is a transformation of the singular transparency of ordinary glass and an inevitable product of development the of glass deep processing towards high technology and intelligence.Patterned Smart switchable Glass is a new type of smart switchable glass,
which can be customized with graphic, company logo and other images on the film, and also is a laminated glass combined with two pieces of glass panel and a PDLC smart film. The glass thickness, colors and types can be customized.

Item Description					Standard PDLC Glass(Tempered Extra Clear)
Optical Test	Transmittance(Visable)	ON	78%+/-2%
				OFF	60.0%
Optical Test	Transmittance(Parellel)	ON	>75%
				OFF	<6%
		Haze	ON	<5%
				OFF	>90%
		Visual Angle	ON	>140°
		UV Resistance	ON	>99%
				OFF	>99%
		IR Resistance	ON	>15%
				OFF	>40%
Eletrical Test	Working Voltage	ON	AC 48-60V
		Saturation Voltage	ON	AC 60V
		Response Time	ON-OFF	200ms
		Power Consumption	ON	6w/sqm
Mechanical Parameter	Thickness			10-18mm
		Maximum Size			1800*3500mm
Environmental Parameter	Working Temperature			-10°C - 65°C
		Storage Temperature			-10°C - 40°C
		Service Life			>50000 hours
		Switch Frequency			> 1000000 times

Working principle

Wiring instructions

Control methods: manual switch, touch switch, voice control, IR sensor, remote control and smart mobile phone APP etc.

1.Privacy protection. As most important function, smart glass can be changed from transparent to opaque via easy model ON & OFF. 2. Perfect function of safety. As smart glass is a special kind of laminated glass, it has all the good function of the laminated glass, mainly the security. 3. Blocks more than 99% UV rays ,avoiding fading in the room. 4. Sound proof. With excellent damping action, the smart glass is easy to block the noise. 5.Projection. When it is under suitable light, the perfect projection appears. 6.No trouble of curtain setting and cleaning. 7.With a modern looking, very good for interior design.

Currently, this product has been widely applied in the sheds, doors, windows and ceilings of car, bath room, shower enclosure, villas, Conference room, insurance companies, supermarket ,hotels, restaurants, churches and command centers. PDLC film applying in luxury hotels, flats and family shower rooms can turn to transparent or opaque easily according to user’s need, which not only ensures personal privacy, but also adds more zest for life.

SMART GLASS for displaying and Security

In banking, jewelry industry and exhibition industry counters, bulletproof glass and glass of display are made with switchable smart glass. When robbery happens, the glass can instantaneously turn into opaque through a variety of ways like remote control so that criminals lose their target which can guarantee maximize personal and property safety.

SMART GLASS for hospital

Smart glass can take the place of curtains in the application for medicali nstitutions. Its firmness, safety, noise insulation and environmental protection can help calm the patients down and recovery. It is used in private clinical areas, nurseries, emergency rooms, ICUs, operation rooms.

SMART GLASS for projection screen

Application for 2D/3D computer and TV monitor, 3D glasses are no more needed when watching a movie or playing online game. Smart glass can be used in projection screen. The application is as the projection screens of shopping plazas, It will function as electronic glass curtain for inner heat insulation in the day time, In the evening, it would be the perfect large free billboard, flash advertisements on it attract public attention.

1.Is there light in the glass? There is no light in the smart switchable glass, it will change constantly just because the liquid crystal film inside is designed to be dynamically changing. 2.How does it look different from the outside and inside? There are not only liquid crystal films in the glass,but also color films with water ripple or cloud effect,which will show different effects when viewed at different angles. 3.Can the glass stay on an effect? Yes,you can.The display is to let everyone understand its various effects,so it is set to automatically switch,in fact,you can use the remote control to control the glass to stay at any effect,simple and convenient. 4.Can it be changed to other effects? Yes,you can.The style and change effect of the graphics, the type and color of the glass, and the material of the outer frame can be customized to the type you want. We have many cases for reference. 5.What is the difference between invisible smart shutter glass(smart switchable glass blinds) produced by our company and traditional shutter glass? 1)It is composed of two layers of glass and a layer of special liquid crystal material laminated glue, and the thickness is 12mm which takes up less place. 2)It is an electronic blind that can have a variety of changes and can be adjusted as needed. 3)There is no hollow layer inside the glass,so there is no fog,no condensation,no dust and no cleaning is required. 4)State changes require no motor control,no lubrication and no sound. 5)The devision of the shutter is the division of the internal material,and the division marks of the edge are basically not seen,and the visual effect is mare natural and beautiful. 6)It can be used not only as a window,but also as a partition,glass door or funiture,etc.
